Converting NO2 to NO for NOx measurements
Fields of application
Combustion and power plants, waste-to-energy and incineration, steel mills, furnace control, continuous emission monitoring systems, research laboratories and other processes.
Features
Innovative NOx or NO2-to-NO converters enable a gas analyser, which usually measures only NO, to accurately determine the total concentration of nitrogen oxides (NOx, which is the sum of NO and NO2). They convert the existing quantity of nitrogen dioxide in the exhaust or flue gas into a single form, namely nitrogen monoxide.
| Catalyst | Volume: 2 / 4 / 6 cm³ Replacement cycle: approx. every 12 months with O2=5% and NO2=10 ppm |
| Temperature control | PXE4 temperature controller Temperature setting: 220°C; K thermocouple |
| Materials in contact with gas | Ceramic, Viton, glass wool, SS316 |
| Conversion rates | 95% or more ENI 5267 / QAL1 compliant |
| Sampling conditions | Flow rate 0.5 l/min Dust- and condensate-free 150°C or less |
| Ambient temperature | -5 °C to +45 °C |
| Power supply | 110 to 240 VAC, 50/60 Hz, approx. 85 VA |
| Contact output | Temperature alarm |
| Dimensions | 212(H) x 148(W) x 130(D) mm |
| Weight | 1.2 kg |
Technologies
Convert NO2 to NO for your NO measurements and monitor your atmospheric emissions with Fuji Electric's NOx converter with very high conversion rate.
NOx converter - NO2/NO - ZDL
Reference : ZDL05001
